1GE 3FE Wifi ONU Router – High-Speed Fiber Router for FTTH Deployments
- 1 GPON/XPON fiber interface
- 1 Gigabit Ethernet interface (1GE)
- 3 100 Gigabit Ethernet interfaces (3FE)
- 1 telephone interface (POTS)
- 1 USB interface
- 1 CATV (Cable TV) interface
- Support 2.4GHz WiFi (802.11b/g/n)
Free Quote
Product Overview
The X6403C is an advanced XPON ONT device designed to deliver high-speed internet, VoIP, IPTV, and CATV services. Ideal for Fiber-to-the-Home (FTTH) deployments, this router combines robust performance with versatile connectivity options, making it perfect for both residential and small business environments.
Key Features OF 1GE 3FE Wifi ONU Router
- 1GE + 3FE Ports: 1 Gigabit Ethernet port and 3 Fast Ethernet ports for high-speed wired connections.
- 2.4G WiFi: Supports 802.11b/g/n wireless standards with 5dBi external dual antennas for extended coverage.
- VoIP Support: Integrated telephone port for VoIP services using H248/SIP protocols.
- CATV Interface: Delivers cable TV signals with high-quality output.
- USB 2.0 Port: Allows for configuration backup and restoration.
- XPON Technology: Single fiber connection with a maximum transmission distance of 20km.
- Power Outage Report: Ensures network reliability with power outage reporting.
- Local WEB Management: Easy configuration and management via a user-friendly web interface.
Technical Specifications OF 1GE 3FE Wifi ONU Router
| Technical Items | Description |
|---|---|
| Out Port Contains | 1GE + 3FE + 1TEL + CATV + 1USB + 5db WiFi |
| WiFi Signal | 2.4G WiFi |
| Wireless Gain | 5db |
| USB | USB 2.0 |
| LAN | 1*10/100/1000Mbps adaptive Ethernet Ports, full/half duplex, RJ45 interface |
| TEL | H248/SIP Voice Protocol |
| PPPoE/BRIDGE | Support |
| Firmware | English |
| Package Dimensions/Weight | 325mm * 173mm * 35mm / 500g |
| Fiber Port | 1GE-GPON/XPON interface, single-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps |
| Wavelength | Tx 1310nm, Rx 1490nm |
| Fiber Interface | SC/UPC Dual mode/Single mode |
| Rx Sensitivity | >28dBm (1490nm) |
| DC Power | 12V/1.0A, external AC-DC power adapter |
| Operation Temperature | -5°C to +55°C |
| Storage Temperature | -30°C to +60°C |
Applications
The X6403C 1GE 3FE Wifi ONU Router is ideal for:
- Residential broadband access
- Small business networks
- VoIP telephony services
- IPTV and CATV distribution
- Fiber-to-the-Home (FTTH) deployments
Why Choose X6403C ?
- High-Speed Connectivity: With 1GE and 3FE ports, enjoy fast and reliable wired connections.
- Extended WiFi Coverage: Dual external antennas ensure strong and stable wireless signals.
- Versatile Services: Supports internet, VoIP, IPTV, and CATV, all in one device.
- Easy Management: Local WEB management simplifies configuration and monitoring.
- Reliable Performance: Designed for stable operation in various environments.
