1GE GPON EPON ONT Modem – High-Performance Fiber Modem for FTTH, FTTO, and FTTD Applications
- PON interface: 1 E/GPON port (EPON PX20+ and GPON Class B+)
- Wavelength: 1310nm to transmit and 1490nm to receive
- Connector: SC/UPC
- Transmission distance: 20KM
- LAN interface: 1 10/100/1000Mbps and 3 10/100Mbps RJ45 ports
- Wireless interface: 2.4G Wifi, compliant with IEEE802.11b/g/n standard
- POTS interface: 1 x FXS, RJ11 connector
- USB port: USB 2.0
- Power supply: DC 12V, 1/1.5A
- Power consumption: ≤10W
- Size: 170mm×140mm×30mm (Length×Width×Height)
- Net weight: 0.243Kg
Free Quote
Product Overview
The 1GE GPON EPON ONT Modem is a state-of-the-art device designed to meet the demands of modern broadband networks. Supporting both GPON and EPON standards, this modem is ideal for Fiber to the Home (FTTH), Fiber to the Office (FTTO), and Fiber to the Desk (FTTD) applications. With advanced features like dual-mode support, robust WiFi capabilities, and a powerful firewall, this modem ensures reliable and secure connectivity.
Key Features of 1GE GPON EPON ONT Modem
- Dual Mode Support: Compatible with both GPON and EPON networks.
- Advanced WiFi: Supports 802.11n WiFi with MIMO technology, offering speeds up to 300Mbps.
- Robust Firewall: Integrated NAT and firewall functions for enhanced security.
- Multiple Interfaces: Includes 1 GE port, 3 FE ports, 1 POTS port, and USB 2.0.
- Remote Management: Supports OAM for easy remote configuration and maintenance.
- Wide Temperature Range: Operates reliably in temperatures from 0℃ to +50℃.
Technical Specifications of 1GE GPON EPON ONT Modem
| Feature | Specification |
|---|---|
| PON Interface | 1 E/GPON port (EPON PX20+ and GPON Class B+) |
| LAN Interface | 1 x 10/100/1000Mbps, 3 x 10/100Mbps |
| Wireless | IEEE802.11b/g/n, 2.4GHz, up to 300Mbps |
| POTS Interface | 1 FXS, RJ11 connector |
| USB Interface | USB 2.0 |
| Power Supply | DC 12V, 1/1.5A |
| Dimensions | 170mm x 140mm x 30mm |
| Weight | 0.243Kg |
Applications
The 1GE ONT Modem is perfect for a variety of applications, including:
- Fiber to the Home (FTTH)
- Fiber to the Office (FTTO)
- Fiber to the Desk (FTTD)
- SOHO Broadband Access
- Video Surveillance
