2.4G WiFi XPON ONU – Dual-Mode EPON/GPON Fiber Optic Terminal for FTTH, FTTO, and FTTD Applications
- 1 Gigabit Ethernet interface (1GE)
- 3 100-megabit Ethernet interfaces (3FE)
- 1 POTS telephone interface (supports VoIP)
- 1 USB 2.0 port
- Built-in 2.4GHz WiFi (supports IEEE 802.11b/g/n, maximum speed of 300Mbps)
- 1 E/GPON port, supporting EPON PX20+ and GPON Class B+ standards.
- Wavelength: 1310nm for transmission, 1490nm for reception.
- Transmission distance: 20 km.
- Power supply: DC 12V, power consumption ≤10W.
Free Quote
Product Overview
The X7403A is a high-performance 2.4G WiFi XPON ONU that supports both EPON and GPON dual-mode fiber access. Designed for FTTH (Fiber to the Home), FTTO (Fiber to the Office), and FTTD (Fiber to the Desk) applications, this ONU offers robust connectivity and advanced features to meet the demands of modern broadband networks.
With its 1GE+3FE+1POTS+WiFi+USB interface configuration, the GL-X8004U-YD provides versatile connectivity options, including high-speed internet, VoIP telephony, and wireless networking. It is an ideal solution for residential, commercial, and small office environments.
Key Features of 2.4G Wifi XPon ONU
- Dual-Mode Support: Compatible with both EPON (PX20+) and GPON (Class B+) standards.
- 2.4G WiFi: Built-in 2.4GHz WiFi (IEEE 802.11b/g/n) with support for MIMO, offering speeds up to 300Mbps.
- Rich Interface Options:
- 1 x Gigabit Ethernet (10/100/1000Mbps)
- 3 x Fast Ethernet (10/100Mbps)
- 1 x POTS (VoIP telephone port)
- 1 x USB 2.0 port
- Advanced Networking Features:
- Support for NAT, firewall, and IPv4/IPv6 dual stack.
- QinQ VLAN and IGMP Snooping for efficient multicast traffic handling.
- Remote Management: Integrated OAM for easy remote configuration and maintenance.
- Wide Temperature Range: Operates in temperatures from 0℃ to +50℃, making it suitable for various environments.
- Plug-and-Play: Auto-detection, auto-configuration, and auto firmware upgrade for easy installation.
Technical Specifications of 2.4G Wifi XPon ONU
| Feature | Specification |
|---|---|
| PON Interface | 1 E/GPON port (EPON PX20+ and GPON Class B+), Wavelength: Tx1310nm, Rx1490nm, SC/UPC connector, Transmission distance: 20KM |
| LAN Interface | 1 x 10/100/1000Mbps, 3 x 10/100Mbps, RJ45 connector |
| Wireless | IEEE 802.11b/g/n, 2.4GHz, MIMO support, up to 300Mbps, Multiple SSID, 13 channels |
| POTS Interface | 1 FXS, RJ11 connector, Supports G.711/G.723/G.726/G.729 codec, Fax mode (T.30/T.38/G.711), DTMF Relay |
| USB Interface | USB 2.0 |
| Power Supply | DC 12V, 1/1.5A |
| Power Consumption | ≤10W |
| Dimensions | 15 x 10.3 x 3.6 cm (L x W x H) |
| Net Weight | 0.21Kg |
Applications
The GL-X8004U-YD is ideal for a wide range of applications, including:
- FTTH (Fiber to the Home): Provides high-speed internet and VoIP services for residential users.
- FTTO (Fiber to the Office): Offers reliable connectivity for small to medium-sized offices.
- FTTD (Fiber to the Desk): Delivers high-speed network access directly to desktop devices.
- SOHO (Small Office/Home Office): Perfect for small businesses requiring robust internet and telephony services.
- Video Surveillance: Supports high-bandwidth applications like IP cameras and video streaming.
Why Choose X7403A?
- Dual-Mode Flexibility: Compatible with both EPON and GPON networks, offering greater deployment flexibility.
- Advanced WiFi: 2.4G WiFi with MIMO technology ensures stable and high-speed wireless connections.
- Comprehensive Connectivity: Multiple Ethernet ports, VoIP support, and USB connectivity cater to diverse user needs.
- Robust Security: Built-in NAT and firewall features ensure secure network operations.
- Easy Maintenance: Remote OAM support simplifies configuration and troubleshooting.
