AX1800 WiFi ONU Router – X8418 High-Performance FTTH Router
Size: 204 x 148 x 40mm
Weight: 403g
Optical Interface: 1 x GPON/EPON (SC/UPC)
Ethernet Interface: 4 x 10/100/1000Mbps GE LAN
Wireless Network: Dual Band WiFi 6 (2.4GHz & 5.8GHz), 2T2R External Antenna, Maximum Rate 1800Mbps
Voice Interface: 1 x RJ11 VoIP Interface
USB Interface: 2 x USB
Power Input: 100V~240V AC, 12V DC, 1.5A
Power consumption: <10W
Operating temperature: -10°C to +45°C
Ambient Humidity: 5% to 95% (non-condensing)
PON Transmission Distance: 0~20km
PON transmission rate: GPON: uplink 1.244Gbps, downlink 2.488Gbps; EPON: uplink and downlink 1.244Gbps
Wireless protocol: IEEE 802.11 b/g/n/ac/ax
Free Quote
Product Overview
The X8418 AX1800 WiFi ONU Router is a high-performance, low-power consumption Optical Network Unit (ONU) designed for Fiber-to-the-Home (FTTH) networks. With its compact design and advanced features, it is ideal for various data service applications in FTTH scenarios. This router supports dual-band WiFi 6, GPON/EPON compatibility, and offers robust routing and switching capabilities, making it perfect for both home and small business use.
Key Features of AX1800 Wifi ONU Router
- Dual-Band WiFi 6: Supports 2.4GHz and 5.8GHz bands with a maximum wireless speed of 1800Mbps.
- GPON/EPON Compatibility: Automatically switches between GPON and EPON modes, compliant with IEEE 802.3ah and ITU-T G.984.x standards.
- Multiple Interfaces: 4 GE LAN ports, 1 VoIP port, 2 USB ports, and dual-band WiFi for versatile connectivity.
- Advanced Routing: Supports Layer 3 routing, hardware NAT, multiple WAN modes, and IPv4/IPv6 dual-stack.
- Voice Support: Integrated VoIP with SIP protocol and support for G.711/G.723/G.726/G.729 codecs.
- Remote Management: Supports TR-069 for remote configuration, maintenance, and software upgrades.
- Firewall & Security: Built-in firewall, URL/MAC/IP filtering, and support for IGMP multicast.
Specifications of AX1800 Wifi ONU Router
| Category | Details |
|---|---|
| Dimensions | 204 x 148 x 40mm |
| Weight | 403g |
| Optical Interface | 1 x GPON/EPON (SC/UPC) |
| Ethernet Ports | 4 x 10/100/1000Mbps GE LAN |
| Wireless | Dual-band WiFi 6 (2.4GHz & 5.8GHz), 2T2R external antenna, up to 1800Mbps |
| Voice Interface | 1 x RJ11 VoIP port |
| USB Ports | 2 x USB |
| Power Supply | 100V~240V AC, 12V DC, 1.5A |
| Power Consumption | <10W |
| Operating Temperature | -10°C to +45°C |
| Humidity | 5% to 95% (non-condensing) |
Highlights
- Superior WiFi Performance: Dual-band WiFi 6 ensures fast and reliable wireless connectivity.
- Wide Compatibility: Compatible with 95% of third-party OLTs, including Huawei, ZTE, and Fiberhome.
- Flexible Operation Modes: Supports PPPoE, DHCP, Static IP, and Bridge modes.
- Easy Management: Supports ONU auto-discovery, link detection, and remote software upgrades.
- Enhanced Security: Built-in firewall, port forwarding, and loop detection for secure networking.
Applications
The X8418 AX1800 WiFi ONU Router is ideal for:
- Residential FTTH deployments
- Small and medium-sized businesses
- Multi-dwelling units (MDUs)
- Voice, data, and video services over FTTH networks
