GPON/EPON ONT Device – Dual-Band WiFi 5 AC1200, VoIP Support
Interface: 1* G/EPON+4*GE+1*FXS+2*USB
Power adapter input: 100V-240V AC, 50Hz-60Hz
Power Supply: DC 12V/1.5A
Power Consumption: <18W
Working temperature: -20℃～+50℃
Environment humidity: 5% ~ 95% (non-condensing)
Dimension：205mm x130mm x38mm
Net Weight：0.38Kg
Free Quote
Product Overview
The X7412A is a high-performance GPON/EPON ONT Device designed for Fiber-to-the-Home/Office (FTTH/O) networks. It integrates dual-band Wi-Fi, VoIP support, and multiple high-speed interfaces, making it ideal for converged voice, data, and video services.
Key Features of GPON/EPON ONT Device X7412A
- Dual-Mode PON Support: Compatible with both GPON (ITU-T G.984.x) and EPON (IEEE 802.3ah) standards.
- AC1200 Dual-Band Wi-Fi: 2.4GHz (300Mbps) + 5GHz (866Mbps) with 4 external antennas.
- Multi-Service Ports: 4× Gigabit LAN, 1× FXS (VoIP), 2× USB, and SC/UPC fiber port.
- Advanced VoIP Support: RJ11 POTS interface with G.711 codec for crystal-clear voice calls.
- Carrier-Grade Management: TR-069 remote configuration, IPv4/IPv6, and hardware NAT acceleration.
Technical Specifications of GPON/EPON ONT Device X7412A
| Category | Details |
|---|---|
| PON Interface | SC/UPC, CLASS B+ Transmission Distance: 0-20km GPON: 2.488Gbps Down / 1.244Gbps Up EPON: 1.244Gbps Symmetric |
| Ethernet | 4× RJ45 (10/100/1000BASE-T) |
| Wireless | 802.11 b/g/n (2.4GHz), 802.11 a/n/ac (5GHz) Max Speed: 1200Mbps Antenna: 4× 5dBi External |
| Power & Dimensions | Input: 100-240V AC Output: DC 12V/1.5A Size: 205×130×38mm Weight: 0.38kg |
SEO-Optimized Highlights
- Best-in-class GPON EPON ONT Device for FTTH deployments.
- Seamless compatibility with major OLTs and automatic GPON/EPON mode adaptation.
- Dual-band Wi-Fi 5 (AC1200) ensures high-speed wireless connectivity.
- Robust VoIP support with FXS interface for legacy telephony integration.
- Energy-efficient design with <18W power consumption.
Applications
- Residential fiber broadband access with whole-home Wi-Fi coverage.
- SMB networks requiring VoIP, multi-WAN, and QoS prioritization.
- Carrier-grade ONT solutions for ISPs and telecom operators.
