ONT Optical Network Terminal – E62 High-Performance Fiber Optic Solution for FTTH
- Product Type: Bridge-type ONT for FTTH
- Modes: Bridge & NAT (Router) Mode
- Power Supply: 12V/0.5A DC Adapter
- Power Consumption: <9W
- Dimensions: 11.5 × 9.5 × 2.5 cm
- Weight: 0.116 kg
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -40°C to 85°C
Free Quote
Product Overview
The X8011U-HZ/E62 is a bridge-type ONT Optical Network Terminal designed for FTTH (Fiber to the Home) solutions. It enables users to access ultra-wideband through EPON (Ethernet Passive Optical Network) technology, providing high-speed internet, HD video, and VOIP services. With its advanced features and robust performance, it is an ideal choice for both residential and small business applications.
Key Features of ONT Optical Network Terminal
- HGU ONU Product Modality: Supports both bridge and NAT modes.
- 802.11b/g/n Wireless Access: Provides up to 300Mbps wireless connectivity.
- VOIP Port: Supports connecting normal telephones with advanced voice features.
- 1GE + 1FE + 1POTS Interfaces: Ensures high-speed data transfer and voice communication.
- 12V/0.5A External Power: Compact and efficient power supply.
Technical Specifications of ONT Optical Network Terminal
| Feature | Details |
|---|---|
| PON Port | 1.25Gbps upstream and downstream |
| Wavelength | Tx: 1310nm, Rx: 1490nm |
| Optical Output Power | EPON: -1 to +4dBm |
| Sensitivity | EPON: -26dBm |
| LAN Ports | 1 x 10/100/1000Mbps, 1 x 10/100Mbps |
| Wireless | IEEE 802.11b/g/n, 300Mbps, 2T2R |
| Power Consumption | <9W |
| Dimensions | 11.5 x 9.5 x 2.5 cm |
| Weight | 0.116kg |
| Operating Temperature | 0 to 50°C |
| Storage Temperature | -40 to 85°C |
VOIP Features
- Voice Coding: ITU-T G.711, G.723.1, G.729
- IP Address Assignment: Dynamic PPPoE/DHCP or static IP
- Call Loss: Less than 0.01%
- Advanced Functions: Echo cancellation, fax support, multi-party conferencing, call forwarding, and more.
Network Features
- EPON/GPON Support: Complies with IEEE 802.3ah EPON standard.
- IPv4 & IPv6 Support: Ensures future-proof network compatibility.
- Multiple WAN Modes: Supports both Router and Bridge modes.
- Layer 2 Features: VLAN, QoS, ACL, IGMP V2, and MLD proxy/snooping.
- Security: DDNS, ALG, DMZ, Firewall, and UPnP support.
Applications
The X8011U-HZ/E62 ONT Optical Network Terminal is ideal for:
- FTTH (Fiber to the Home): Provides high-speed internet, IPTV, and VOIP services for residential users.
- Small Business Networks: Offers reliable and secure connectivity for small office environments.
- Multi-Service Networks: Supports simultaneous data, voice, and video services over a single fiber connection.
