ONU Router with WiFi – High-Performance FTTH Router for Home and Small Business Networks
- 1 G/EPON fiber interface.
- 4 10/100/1000Mbps Ethernet interfaces (RJ45).
- 1 FXS telephone interface (RJ11).
- 2 USB interfaces.
- 2 external 2.4GHz/5GHz Wi-Fi antennas.
Free Quote
Product Overview
The X7412 is a state-of-the-art ONU router with WiFi, designed for Fiber-to-the-Home/Office (FTTH/O) scenarios. This versatile device combines high-speed internet access, dual-band WiFi, and VoIP services, making it an ideal solution for modern home and small business networks.
Key Features of ONU Router with WiFi
- Dual-Band WiFi: Supports 2.4GHz and 5GHz bands with speeds up to 300Mbps and 866Mbps respectively.
- Multiple Ethernet Ports: 4 x Gigabit Ethernet ports for high-speed wired connections.
- VoIP Support: 1 x POTS port for VoIP services with G.711 codec support.
- USB Ports: 2 x USB ports for additional connectivity options.
- GPON/EPON Compatibility: Automatically adapts to GPON or EPON modes used by the OLT.
- Advanced Network Features: Supports IPv4/IPv6, TR-069 remote management, VLAN, QoS, and more.
Specifications
| Category | Details |
|---|---|
| Interfaces | 1 x G/EPON, 4 x GE, 1 x FXS, 2 x USB, 2.4G/5G WiFi |
| Power Supply | 100V-240V AC, 50Hz-60Hz; DC 12V/1.5A |
| Power Consumption | <18W |
| Working Temperature | -20℃ to +50℃ |
| Dimensions | 180mm x 140mm x 35mm (without antenna) |
| Net Weight | 0.3Kg |
| PON Interface | SC/APC, CLASS B+; Transmission distance: 0-20km |
| WiFi Specifications | 2.4GHz: 802.11 b/g/n, 300Mbps; 5GHz: 802.11 a/n/ac, 866Mbps |
| VoIP Interface | 1 x FXS, RJ11 connector; G.711 codec |
Why Choose the GL-X8124U-MTK?
The X7412 is a highly configurable and cost-effective ONU router with WiFi, offering a comprehensive set of features for both home and small business environments. Its dual-band WiFi, multiple Ethernet ports, and VoIP support make it a versatile choice for modern networking needs.
Get Your ONU Router with WiFi Today!
Enhance your network with the X7412. Contact us now for more information or to place your order.
