Single Port CATV ONT Modem – 1GE 1 Port GPon/EPon Dual Mode ONU for FTTX
- Interfaces: 1* G/EPON + 1* GE + 1* RF + 1* CATV
- Power adapter input: 100V-240V AC, 50Hz-60Hz
- Power supply: DC 12V/1A
- Indicators: POWER/PON/LOS/LAN1/RF/OPT
- Buttons: Power On/Off button, Reset button
- Power Consumption: <18W
- Operating Temperature: -20℃～+55℃
- Ambient Humidity: 5% ~ 95% (non-condensing)
- Dimensions: 157mm x 86mm x 28mm (L x W x H without antenna)
- Net Weight: 0.15Kg
- Interface Type: SC/APC, CLASS B+
- Transmission Distance: 0-20km
- Operating Wavelength: Uplink 1310nm; Downlink 1490nm; CATV 1550nm
Free Quote
Product Introduction
The X31C is a state-of-the-art Single Port CATV ONT Modem designed for residential and SOHO users. It supports both EPON and GPON standards, offering a robust solution for FTTH (Fiber to the Home) and FTTB (Fiber to the Building) applications. With its integrated CATV interface, it provides seamless video service alongside high-speed internet access.
Key Features of Single port CATV ONT Modem
- Compliance with IEEE 802.3ah (EPON) & ITU-T G.984.x (GPON) standards
- Support for IPv4 & IPv6 management and transmission
- TR-069 remote configuration and maintenance
- Layer 3 gateway with hardware NAT
- Multiple WAN configurations with Route/Bridge mode
- Layer 2 802.1Q VLAN, 802.1P QoS, and ACL support
- IGMP V2 and MLD proxy/snooping
- DDNS, ALG, DMZ, Firewall, and UPnP services
- Integrated CATV interface for video services
- Bi-directional FEC support
Highlights
- Compatibility with OLTs from various manufacturers
- Automatic adaptation to EPON or GPON modes
- Multiple WAN configurations
- Support for WAN PPPoE/DHCP/Static IP/Bridge modes
- CATV video service support
- Fast hardware NAT transmission
Hardware Specifications of Single port CATV ONT Modem
| Interface | 1* G/EPON + 1* GE + 1* RF |
|---|---|
| Power Adapter Input | 100V-240V AC, 50Hz-60Hz |
| Power Supply | DC 12V/1A |
| Indicator Lights | POWER/PON/LOS/LAN1/RF/OPT |
| Buttons | Power switch, Reset |
| Power Consumption | <18W |
| Working Temperature | -20℃～+55℃ |
| Environment Humidity | 5% ~ 95% (non-condensing) |
| Dimensions | 157mm x 86mm x 28mm (L×W×H, without antenna) |
| Net Weight | 0.15Kg |
Application Scenario
The X31C is ideal for residential and small office environments, providing reliable and high-speed internet access along with CATV video services. It is perfect for FTTH and FTTB deployments, ensuring seamless connectivity and multimedia services.
