Wifi ONU 2 Ports – High-Performance XPON ONT Modem Terminal
- 1 GPON/EPON port
- 1 10/100/1000Mbps LAN port
- 1 10/100Mbps LAN port
- 1 FXS POTS port (supports VOIP)
- Wireless: IEEE 802.11b/g/n, supports 2T2R, up to 300Mbps
- Power: 12V/1.5A external power adapter
- Power Consumption: <9W
- Dimensions: 143mm(L) x 100mm(W) x 28mm(H)
- Weight: <0.3kg
Free Quote
Product Overview
The Wifi ONU 2 Ports G52 is a high-performance XPON terminal designed for home and small office networks. It features 1GE, 1FE, and 1POTS ports, and it builts-in 2.4G Wifi with 300Mbps max transmission rate. Making it a versatile solution for various networking needs. With its robust design and advanced features, this ONU ensures reliable and high-quality connectivity.
Key Features OF Wifi ONU 2 Ports
- HGU ONU Product Modality: Supports bridge and NAT modes.
- Wireless Access: IEEE 802.11b/g/n, 2T2R, up to 300Mbps.
- VOIP Support: 1 FXS port for connecting normal telephones.
- Power Supply: 12V/1.5A external power adapter.
- Compact Design: Dimensions of 143mm(L) x 100mm(W) x 28mm(H), weight <0.3kg.
Technical Specifications of Wifi ONU 2 Ports
| Interface | 1 GPON/EPON, 1 10/100/1000Mbps LAN, 1 10/100Mbps LAN, 1 FXS POTS |
|---|---|
| Wireless | IEEE 802.11b/g/n, 2T2R, up to 300Mbps |
| Power | 12V/1.5A external power adapter, <9W power consumption |
| Dimensions | 143mm(L) x 100mm(W) x 28mm(H) |
| Weight | <0.3kg |
| Operating Temperature | 0℃ ~ 50℃ |
| Storage Temperature | -40℃ ~ 85℃ |
| Operating Humidity | 10% ~ 90% (Non-condensing) |
| Storage Humidity | 10% ~ 90% (Non-condensing) |
Supported Protocols and Standards
- GPON: ITU-T G.984
- EPON: IEEE 802.3ah
- VOIP: SIP, G.711, G.723.1, G.729
- Other: IEEE 802.1d, IEEE 802.1p, IEEE 802.1q, IEEE 802.1x, RFC1155, RFC1157, RFC1112, RFC1113
Applications
The G52 is ideal for:
- Home networks
- Small office networks
- Fiber-to-the-Home (FTTH) deployments
- VOIP telephony services
